GMARK factory produces PVC foam adhesive tape for the construction industry
PVC Foam Glazing tape(Spacer Tape) is used PVC foam as carrier, which is coated both sides with high tack acrylic adhesive with blue filmic liner for easy release which has a closed cell structure to allow curing of structural silicones on all sides of the joint. It is usually used to create a seal between a double glazed unit and the frame on both windows and doors.
Download Message
Product Details
GMARK factory produces PVC foam adhesive tape for the construction industry
The main materials of the double-sided PVC foam tape are PVC foam and both sides are coated with glue. Mainly applied to the sealing of the double-city glass unit and the frame of doors and windows, etc.
► Product Details
►Product Technical Specification
| Thickness | 1mm-25mm | Adhesive | Acrylic pressure sensitive |
| Width | 10-1050mm | Density | 90kg/m3-450kg/m3 |
| Length | 10-15m | Peel adhesion | 46N/25mm |
| Color | White or black color foam | Elogation | 3% |
| Release Liner | Tensile strength paper or film liner | Holding power | 48N/25MM |
| Backing | PVC FOAM | Hardness | 65-100degree |
► Application
˃ replaces the uses of clips thus avoids labor cost.
˃ Specially used for aluminum doors, window, steel, aluminum surface and panel fixing.
˃ Highly suitable thermal insulation thus seals against water, vapor and noise.
˃ Highly suitable for structural glazing as a spacer.
